SOM-Q7-BT

Computer on Module (CoM) Qseven® Rel. 2.0 Compliant con Processori Intel® Atom™ E3800 e Celeron® (Codename: Bay Trail). (AVIOR - 974)

Disponibile nell'intervallo di temperatura industriale

Data sheet

Contattaci per maggiori informazioni e per preventivi

Contattaci

Cpu

Intel® Atom™ E3800 and Celeron® families of System-on-Chip

Grafica

Integrated Intel® HD Graphics controller

Connettività

6x USB 2.0; 1x USB 3.0; 3x PCI-e x1

Memoria

up to 8GB Dual-Channel DDR3L 1333MHz

Ready for DevOps

A toolkit is available for all SECO solutions to increase developer productivity and simplify fleet management.

Device
Manager

Make the most of your devices by integrating your software, developing new features, and connecting to our IoT platform Clea to harness the full power of IoT.

Modular design

Take control of your software on Edgehog OS through Docker containers, harnessing unprecedented flexibility and customization.

Designed for IoT

All SECO hardware seamlessly integrates with Clea. Develop new software using Clea's SDKs, manage your data online, incorporate the power of workflow automation into your services, and monetize your product on our app framework.

Open source

Commitment to open source is a cornerstone of our company philosophy. We believe in open collaboration and sharing to foster innovation and sustainable growth in the embedded computing and IoT industry.

Clea docs Edgehog OS docs

Dettagli Prodotto

Informazioni tecniche

Descrizione	SOM-Q7-BT is a Qseven® Rel. 2.0 Compliant Computer on Module (CoM) designed by SECO, based on the Intel® Atom™ E3800 family of System-on-Chip with a 64-bit instruction set. Integrating all the interfaces in a Single Chip, which also embeds a high performance 2D and 3D GPU, this family of SOCs offers a very high level of performance for all kinds of applications, from graphics to industrial automation.
Cpu	Intel® Atom™ E3845, Quad Core @1.91GHz, 2MB Cache, 10W TDP Intel® Atom™ E3827, Dual Core @1.75GHz, 1MB Cache, 8W TDP Intel® Atom™ E3826, Dual Core @1.46GHz, 1MB Cache, 7W TDP Intel® Atom™ E3825, Dual Core @1.33GHz, 1MB Cache, 6W TDP Intel® Atom™ E3815, Single Core @1.46GHz, 512KB Cache, 5W TDP Intel® Celeron® J1900, Quad Core @2.0GHz, 2MB Cache, 10W TDP Intel® Celeron® N2930, Quad Core @1.83GHz, 2MB Cache, 7.5W TDP Intel® Celeron® N2807, Dual Core @1.58GHz, 1MB Cache, 4.3W TDP
Numero Max Core	4
Memoria	Soldered on-board DDR3L memory E3845, E3827, J1900, N2930: up to 8GB Dual-Channel DDR3L @ 1333MHz E3826: up to 8GB Dual-Channel DDR3L @ 1066MHz N2807: up to 4GB Single-Channel DDR3L @ 1333MHz E3825, E3815: up to 4GB Single-Channel DDR3L @ 1066MHz
Grafica	Integrated Intel® HD Graphics 4000 Series controller Dual independent display support HW decoding of H.264, MPEG2, MVC, VC1, VP8, MJPEG formats HW encoding of H.264, MPEG2 and MVC formats
Interfacce video	HDMI or Multimode Display Port interface (factory options) Embedded Display Port or 18/24 bit dual channel LVDS interface (factory options) Additional VGA interface (optional external adapter is required)
Risoluzione video	HDMI Up to 1920x1080p@60Hz Display Port, eDP, CRT Up to 2560x1600 @60Hz Optional LVDS interface Up to 1920x1200@60Hz
Memoria di massa	Up to 2 x external S-ATA channels SD Interface Optional SATA Flash Disk soldered on board
Rete	Gigabit Ethernet interface
USB	1 x USB 3.0 Host port 6 x USB 2.0 Host ports (one shared with USB 3.0)
Pci	3 x PCI-e x1 lanes
Audio	HD Audio Interface
Porte seriali	1 x Serial port (TTL interface)
Altre interfacce	I2C Bus LPC Bus SM Bus Thermal / FAN management SPI interface Power Management Signals
Dispositivo di alimentazione	+5VDC ± 5%
Sistema operativo	Microsoft® Windows 7 (32/64 bit) Microsoft® Windows 8 (32/64 bit) Microsoft® Windows 8.1 (32/64 bit) Microsoft® Windows 10 (32/64 bit) Microsoft® Windows 10 IoT Microsoft® Windows Embedded Standard 7 (32/64 bit) Microsoft® Windows Embedded Compact 7 Linux (32/64 bit) Yocto
Temperatura operativa	0°C ÷ +60°C (commercial version) -40°C ÷ +85°C (industrial version) *Measured at any point of SECO standard heastpreader for this product, during any and all times (including start-up). Actual temperature will widely depend on application, enclosure and/or environment. Upon customer to consider application-specific cooling solutions for the final system to keep the heatspreader temperature in the range indicated.
Dimensioni	70x70 mm (2.76” x 2.76”)

Software

Tools and Documents	[Tools and Documents] - Flash Tools
BIOS	[Bios] - Release version 1.28
EAPI	[Embedded application programming interface] - Release version 1.20.22
Linux-YOCTO	[BSP] - Yocto Pyro [Images] - Sample images (sato and minimal) (pyro 64bit)
Windows Embedded Compact 7	[BSP] - Package version 3.2.0 MR2 V1.0
Windows 8	[LAN - 32 bit] - Driver version 19.1 [LAN - 64 bit] - Driver version 19.1 [Video - 32 bit] - Driver version 15.33.20.3574 [Video - 64 bit] - Driver version 15.33.20.64.3574 [Chipset - 32/64 bit] - Driver version 10.0.17 [I/O drivers - 32/64 bit] - Driver version 545879 [TXE installer only for Nxxx & Jxxx - 32/64 bit] - Driver version 1.1.0.1064
Windows 8.1	[I/O drivers - 32/64 bit] - Driver version MR1 [Chipset - 32/64 bit] - Driver version 10.1.1.8 [Video - 32 bit] - Driver version 15.33.19.3540 [Video - 64 bit] - Driver version 15.33.19.3540 [LAN - 32 bit] - Driver version 19.1 [LAN - 64 bit] - Driver version 19.1 [TXE installer - 32/64 bit] - Driver version 1.0.5.1120
Windows 7	[Chipset - 32/64 bit] - Driver version 10.1.1.8 [Video - 32 bit] - Driver version 36.15.0.1127 [Video - 64 bit] - Driver version 37.15.0.1127 [USB 3.0 eXtensible Host Controller - 32/64 bit] - Driver version 4.0.0.27 [LAN - 32 bit] - Driver version 19.1 [LAN - 64 bit] - Driver version 19.1 [TXE installer - 32/64 bit] - Driver version 1.0.5.1120
Windows Embedded Standard 7	[Chipset - 32/64 bit] - Driver version 10.1.1.8 [I/O drivers - 32/64 bit] - Driver version MR3 [Video - 32 bit] - Driver version 36.15.0.1127 [Video - 64 bit] - Driver version 37.15.0.1127 [USB 3.0 eXtensible Host Controller - 32/64 bit] - Driver version 4.0.0.27 [LAN - 32 bit] - Driver version 19.1 [LAN - 64 bit] - Driver version 19.1 [TXE installer - 32/64 bit] - Driver version 1.0.5.1120
Windows 10	[Video - 64 bit] - Driver version 15.33.19.3540 [Video - 32 bit] - Driver version 15.33.19.3540 [TXE installer - 32/64 bit] - Driver version 1.0.5.1120 [LAN - 64 bit] - Driver version 23.5.1 [LAN - 32 bit] - Driver version 23.5.1 [Serial I/O] - Driver Gold edition [MBI(Sideband Fabric Device) only for Nxxx & Jxxx - 32/64 bit ] - Driver version 604.10125.2655.573 [Chipset - 32/64 bit] - Driver version 10.1.1.8 [IO Tools - 32/64bit] - HSUART Virtual COM sample code (demonstration only) - v1.1 [IO Tools - 32/64bit] - SPB Test Tool sample code (demonstration only) - Build_1265_18_02_22

Documentazione

Data Sheet	[Datasheet] SOM-Q7-BT Rel 2.3
Manual	[Manual] AVIOR Rel 2.3
