DEV-KIT-Q7-2.0 [Discontinued]

Skip to the beginning of the images gallery

DEV-KIT-Q7-2.0 [Discontinued]

In stock

Cross Platform Starter Kit compatible with both x86 and Arm Rev. 2.0 Qseven® modules: a complete package including the basic components necessary to start developing. (Formerly Q7 DEV KIT 2.0)

Request a quote

$0.00

Datasheet

Click to download

Manual

Click to download

Dev Center

Visit page

Clea OS

Visit page

View all resources

The Starter Kit contains: • Carrier board for Qseven® Rev. 2.0 compliant modules CQ7-A42(DP or HDMI® version) • HD Audio module • I2S Audio module • One 12VDC Notebook Power Adapter • Cable kit • Adapter for mounting a microQ7 module on standard Qseven carrier boards Qseven® module not included. Must be purchased separately

Security & Compliance by Design

SECO products integrate security functions that enable out-of-the-box compliance with the RED directive [EN18031-1]. Certification documentation is available upon request. Security monitoring, patching and update automation are powered by Clea.

Secure Boot

Built-in Secure Boot to ensure system integrity from the first startup.

OTA Updates

Remote and secure software update distribution for your devices.

Device Monitoring

Continuous monitoring of device status and activity with Clea.

Secure Operating System

Yocto-based OS integration for customizable and secure system builds.

Certified Security

Compliance with EN18031-1 standards for secure and reliable embedded systems.

Docker Technology

Isolated and flexible application management through containerization.

Application Hub

Discover the applications compatible with this product available on the SECO Application Hub: ready-to-use solutions to accelerate the development and deployment of intelligent features.

Machine Alert Assistance with Operator Recognition

Technical Specifications

Description	The Starter Kit contains: • Carrier board for Qseven® Rev. 2.0 compliant modules CQ7-A42(DP or HDMI® version) • HD Audio module • I2S Audio module • One 12VDC Notebook Power Adapter • Cable kit • Adapter for mounting a microQ7 module on standard Qseven carrier boards Qseven® module not included. Must be purchased separately
Video Interfaces Description	LVDS Dual Channel 24-bit + backlight connectors or 2 x eDP connectors Multimode Display Port or HDMI® Connector
Mass Storage Description	1 x S-ATA connector with HDD Power connector 1 x mSATA Slot microSD Slot on combo microSD + SIM connector
Networking Description	Up to 2 x Gigabit Ethernet connectors
USB Description	1 x USB 3.0 Host port on type-A socket 2 x USB 2.0 Host ports on double Type-A sockets 2 x USB 2.0 Host ports on internal pin header 1 x USB 2.0 OTG port on micro-AB socket (USB port shared with miniPCI-e slot)
PCI Description	miniPCI-e slot Full / Half size, combined with SIM card slot
Audio Description	Audio interface on internal pin header
Serial Ports	4-wires RS-232 / RS-422 / RS-485 configurable serial port on DB9 male connector 2 x RS-232 Full-modem serial ports on internal header (needs LPC interface from Qseven® module) CAN interface on PCB terminal block
Other Interfaces	SPI internal pin header LPC Bus internal pin header SM Bus / I2C GPIO expander, makes available 16 x GPIOs on internal pin header Front Panel Header 1 x 28 pin connector for additional features (I2C, ACPI signals, SM Bus, Watch Dog, Thermal Management) +12V Tachometric FAN connector Optional Debug USB port on miniB socket Optional MFG connector for JTAG programming of Qseven® module
Power Supply	+12VDC Mini-fit Standard ATX power connector Coin cell battery Holder for CMOS and RTC
Operating Temperature Description	-40°C ÷ +85 °C (industrial range) *All carrier board components must remain within the operating temperature at any and all times, including startup; carrier operating temperature is independent of the module installed. Please refer to the specific module for more details. Actual temperature will widely depend on application, enclosure and/or environment. Upon customer to consider specific cooling solutions for the final system.
Dimensions	146 x 102 mm (5,75” x 4,02”)

Part Number

QA42-Q7XSK-2200

Q7 Starter Kit 2.0 - HDMI - LVDS, no display included

Request your sample

Resources

Data Sheet	[Datasheet] Q7 STARTER KIT 2.0 Rel 2.4
Image	[Image] Q7 STARTER KIT 2.0
Manual	[Schematics] Q7 STARTER KIT 2.0 [Manual] Q7 STARTER KIT 2.0
Software Links	SECO Technical Resources
Documentation	3WP1hnc1
